JPJ Audio have a laugh with Russell Peters Qudos Arena Sydney

It’s a common misconception that comedy must be easy to mix as there is only one microphone. Unfortunately with only one mic, you have no place to hide and no-one to blame if it doesn’t sound good. This means having a good sound system, correctly set-up is vital to the FOH engineer.

The audio system JPJ Audio supplied for Russell Peters is amongst the largest we would routinely put in to Qudos Arena. In fact there were more speaker cabinets than we would hang for an average rock concert in the same space!

This is because comedy relies on high intelligibility in the vocal range. If the audience can’t hear every joke, in every seat, they are not going to enjoy the show. If the audience can’t hear, they won’t laugh at the jokes, and this will impact the comedian’s performance (especially if the front rows can’t hear!!!).

Advertisement

This clear audio is achieved through acoustic modelling of the venue prior to arrival, careful placement of the PA hangs, and having enough speaker boxes to achieve the required SPL. This is all sound checked by walking around the edge of every seating block in the venue, with a handheld radio mic and making adjustments to the different PA zones. This verifies that every seat in the house can hear every joke.

The main hangs were two hangs of 12 x L-Acoustics K1 and 6 x L-Acoustics K2 with two hangs of 12 x L-Acoustics K2 for side hangs. Frontfill was 6 x single L-Acoustics Kara, outfill was 4 x L-Acoustics Arcs and subs were 12 x L-Acoustics SB28 Subwoofer Enclosures. All powered by L-Acoustics LA-8 and LA-12 amplifiers.

A Dante drive system using Dolby LM44’s was utilized and this involved running a completely digital signal path from the FOH console all the way to the amplifiers via AES and Dante signal processing.

Advertisement

A seamless back-up analogue audio fallback is also in every system using DANTE. Back-up systems and engineer comfort are critical to industry acceptance, so are always at the forefront of all JPJ Audio designed systems.

FOH engineer for the tour was James Kilpatrick on an Avid Profile with Waves 9. James used a C6 multiband compressor to keep the speech clear at low level and cut the horn band back when shouting. He also had a vocal rider live in reverse to keep the mic level low in between pauses in speech to reduce room tone in the microphone.

Crew:
FOH systems engineer: Tim Seconi
FOH systems technician: Bianca Martin
Monitors systems engineer: Kellie McKee
PA technician: Ben Northmore
Special Guest Appearance Multicores and front fill trainee: Mats Frankl
